Description
The Drallim MC2 helicopter tie-down storm lashing is a proven, lightweight, user-friendly helicopter lashing. It has 60 mm webbing, designed for securing heavier helicopters and would suit most medium helicopters in the in the MTOW: 4-10 tonnes weight category*.
This nylon webbing tie-down has a fast, single action over centre mechanism which gives tension and locking in one easy movement. Unlike inferior ratchet-type lashings, it is impossible to over tension the MC2 storm lashing. Any over-tensioned of lashings can cause significant damage to aircraft parts, often unseen and possibly causing significant unserviceability. Once secured, any slack can be taken up without reloading the mechanism. Release of the unit is a reverse single action.
This product is made to order; contact us for more information.
Made in the UK, the design load is 4536 kg and its ultimate load is 6804 kg.
Key Features
- Designed for helicopters with an MTOW* of approximately 4-10 tonne
- Material: Stainless steel (highly polished)
- Easy to load mechanism
- Quick to release
- Treated to resist abrasion and UV damage
- Unique clutch mechanism
- Impossible to over tension
- Built to last
- Design load: 4536 kg (10,000 lb)
- Ultimate load: 6804 kg (15,000 lb)
- Webbing width: 60 mm
- Length: 6.0 m
- Weight (6.0 m lashing): 4.1 kg (9 lb)
* MTOW – Maximum Take-Off Weight
